demonstration product: bim software system

product info: manage the whole lift cycle of aec industry from design, purchase, construction and operation & maintenance in term of man, material and machine. the complete system adopts light weight web bim model as the core, to expand each model application.

project composition: design management, webgl light weight, revit integration, microstation integration, navisworks integration, system integration, project management, quality management , change management, risk management, safety management, acceptance management, rfi management, file management

technology highlights

  • pre-configured 3d data import interface, auto & semi-auto data conversion process

  • light weight data based on webgl, with light weight rate reaching 1:10

  • keep 3d

    model completeness;

    auto import feature,structure, category data to web & link with model

  • the converted data can be used constantly



demonstration product: plm software system

product info: aras plm provide enterprise level open authorized product life cycle management solution (plm). open authorized mode saves the enterprise with upfront investment cost, plus outstanding technical innovation capability, aras product is a plm software suited for enterprises with complex products and processes. aras innovator is the partner for microsoft in plm region. it is the cmii4 level open authorized enterprise level plm product.

project composition: 1. demand management 2. product planning management 3. configuration management 4. mcad integration 5. ecad integration 6. system integration 7. component management 8. bom management 9. change management 10. archiving management 11. quality management 12. compliance management 13. manufacture process management 14. aftersales management


technology highlights

  •  microsoft soa technical architecture is adopted with high flexibility setting capability

  • open authorized

    plm system, without

    any restriction on

    user quantity;

  • enterprise

    with high implem-

    entation autonomy

    and low threshold, to

    reduceenterprise

    implementation

    risk and cost;

  • adopt most

    popular open

    source community

    to provide open

    app downloading;

  • complete

    technical support

    network to meet

    enterprise demand

    with localized

    service channel;

  • rich and

    diversified  domestic

    implementation

    successful experience

    to tailor-made required service;

  • introduce all

    kinds of action

    platform technology,

    in line with current

    industry information

    action trend;

  • natural b/s system architecture, non-c/s frame revised plm system.
